Elysia xfilter qube

precise. open. versatile.

xfilter qube is a true stereo-linked 4-band equalizer, a rarity among analog EQs, now packed into the rugged, lightweight elysia qube for analog processing on the go. Its two channels are matched using computer-selected dual and quad-layer potentiometers plus low-tolerance capacitors, so both channels behave identically instead of drifting apart the way ordinary linked-mono designs do.

The outer bands double as switchable resonant high- and low-cut filters, the two parametric mid bands offer a choice of wide (Q 0.5) or narrow (Q 1.0) bandwidth, and a switchable passive 'Massage' filter polishes the top end. The qube is fully self-contained with its own internal power supply.

xfilter qube Features & Specs

• 4-band true stereo-linked equalizer for recording, mixing and mastering, in the elysia qube chassis
• Switchable resonant high- and low-cut filters on the outer bands (12 dB/octave)
• Switchable Q (0.5/1.0) on the two parametric mid bands
• Passive Massage: switchable passive high-band filter for extra top-end sheen
• Computer-matched, low-tolerance dual/quad-layer potentiometers, 41 steps
• Self-contained, travel-ready aluminium chassis with internal power supply
• Frequency response: <10 Hz - 400 kHz (-3.0 dB)
• Dynamic range: 112 dB
• Dimensions (W x H x D, incl. knobs): 104 x 137 x 212 mm / 4.09" x 5.39" x 8.4"
• Weight: 1.46 kg / 3.17 lbs
• Power consumption: 10 Watts

DOCUMENTATION:

• 500/qube Series Manual
• Recall Sheet 500/qube Series
