Elysia xfilter|Mastering Edition 19" Rack

Focus on every detail

xfilter|Mastering Edition takes the true stereo-linked 4-band architecture of xfilter and optimizes it specifically for mastering workflows: a precise control range of +/-5 dB on all four bands, stepped 41-position potentiometers for accurate, repeatable recall, and an extended +27 dBu of headroom that preserves pristine quality even at high signal levels.

Like the standard xfilter, it offers switchable Q on the two parametric mid bands, resonant high/low-cut filters on the outer bands, and the passive Massage filter for top-end polish - all matched with computer-selected, low-tolerance potentiometers for true stereo integrity.

xfilter|Mastering Edition Features & Specs

• 4-band true stereo-linked mastering equalizer, 19" rack only
• Precise +/-5 dB control range on all four bands
• Stepped potentiometers, 41 steps, for accurate recall
• Extended +27 dBu headroom for mastering-grade signal levels
• Switchable resonant high- and low-cut filters on the outer bands
• Switchable Q (0.5/1.0) on the two parametric mid bands
• Passive Massage: switchable passive high-band filter
• Frequency response: <10 Hz - 400 kHz (-3.0 dB)
• Dimensions (W x H x D, incl. knobs): 483 x 44.45 x 238 mm / 19" x 1.75" x 9.4"
• Weight: 1.76 kg / 3.88 lbs
• Power consumption: 13 Watts

DOCUMENTATION:

• Rack Series Manual
• Recall Sheet Rack Series
